Toyota Electric Pneumatic (4,000-11,000 LBS)
| Make | Toyota |
| Model | Electric Pneumatic (4,000-11,000 LBS) |
| Type | Electric Forklifts |
How can we help?
Description
Overview
Want to maintain an all electric fleet, but need a rugged, outdoor solution? Look no further than Toyota’s Electric Pneumatic Forklift. Powerful and rugged enough to perform similar to internal combustion counterparts, but running off a battery, Toyota’s Electric Pneumatic Forklift maintains clean air and low maintenance, but supports powerful, outdoor, traditionally IC applications.
Outdoor Electric Forklift Solution
The Toyota Electric Pneumatic is a green, outdoor forklift solution. Instead of supplementing your indoor electric fleet with IC counterparts for your outdoor application, the Electric Pneumatic provides an all-electric option for both indoor and outdoor use.
Continued Performance
According to recent studies by Peerless Research Group, more and more forklift owners plan to keep their forklifts for 10+ years! Just like a car, truck or another motorized asset, periodic maintenance, service and upkeep is required, even under normal operating conditions, to keep your Toyota Electric Pneumatic Forklift operating at peak performance. It is not uncommon for Toyota forklift owners to well exceed 10 years of use, as long as the forklift is properly maintained. Paired with a Planned Maintenance (PM) Plan, the Electric Pneumatic Forklift can be an asset for your company for years to come.
Models
Electric Pneumatic Forklift
| Model Number | Load Capacity* (lbs.) | Max. Travel Speed Full Load (MPH) | Max. Lift Speed Full Load (FPM) | Max. Gradeability Full Load (%) | Basic Right Angle Stack** (IN.) |
|---|---|---|---|---|---|
| 05-8FBM20T | 4,000 | 11.8 | 96 | 26 | 95.4 |
| 05-8FBM25T | 5,000 | 11.8 | 91 | 24 | 100.7 |
| 05-8FBMK25T | 5,000 | 11.8 | 91 | 25 | 95.4 |
| 05-8FBM30T | 6,000 | 11.8 | 75 | 22 | 101.5 |
| 05-8FBMK30T | 6,000 | 11.8 | 75 | 21 | 97.3 |
| 05-8FBM35T | 7,000 | 11.8 | 69 | 19 | 102.6 |
| 8FBM40T | 8,000 | 11 | 68.9 | 15 | 120.5 |
| 8FBM45T | 9,000 | 11 | 68.9 | 14 | 121.1 |
| 8FBM50T | 11,000 | 11 | 65 | 13 | 126.5 |
Specifications
- Length to Forkface: 89.9 - 120.9 in
- Load Capacity: 4,000 - 11,000 lb. Load Capacity
- Overall Width: 47 - 56.7 in
- Overhead Guard Height: 87.2 - 92.9 in
- Travel Speed Full Load: 11 - 11.8 mph Travel Speed Full Load
- Voltage: 80 Voltage
Features
- Can-bus controller wiring
- Electric Horn
- 80 Volt electrical System
- Memory tilt steering column
- Operator Presence Sensing System (OPSS)
- Heavy-duty non-slip floor mat
- Emissions: 0
- Transistor controlled AC lift & drive Motors
- Battery compartment hood assist
- Digital multifunction display
- UL-E conformity
- Retractable Seat Belt (Non-Clinching)
- ORS Non-Suspension vinyl seat
- System of Active Stability (SAS)
- MPH Travel Speed: 11.8
- Easy access no-tools floorboard
- Planned Maintenance Indicator
- FPM Lift Speed: 96
- AC drive motor (no brushes or commutator)
- AC Hydraulic motor (no brushes or commutator)
- 3-way hydraulic control valve
- Double-Action Parking Brake
- AC Controller with MOSFET Design
- Regenerative Braking
- Overhead Guard
