Toyota Stand-Up Rider (3,000-4,000 LBS)
| Make | Toyota |
| Model | Stand-Up Rider (3,000-4,000 LBS) |
| Type | Electric Forklifts |
How can we help?
Description
Overview
The unique dock-to-stock capability of the Toyota Stand-Up Rider Forklift makes it top of its class and one of the most versatile forklifts in Toyota’s product line. Because it is designed for 5,000 lb. loads, it is more flexible and can handle more capacity at greater heights with added durability. Its compact design allows it to seamlessly navigate narrow aisles with ease, giving you the ability to store more products in your facility. This Toyota Forklift delivers improved ergonomics, reliability, and sturdiness while reducing service intervals. The Toyota Stand-Up Rider is a multi-purpose forklift that is ready to work when you are.
Stand Up to the Challenge
Designed with an angled front cover and overhead guard, Toyota’s Stand-Up Rider helps operators gain better visibility and increased efficiency while the forklift is in use. The standard open-view, 4-cylinder mast provides operators with a clear line of sight. Toyota’s Stand-Up Rider delivers top travel and lift/lower speeds courtesy of the AC drive motor.
Models
Stand-Up Rider Forklift
| Model Number | Load Capacity* (lbs.) | Max. Travel Speed Full Load (MPH) | Max. Lift Speed Full Load (FPM) | Max. Gradeability Full Load (%) | Basic Right Angle Stack** (IN.) |
|---|---|---|---|---|---|
| 8BNCU15-16.5 | 3,000 | 7.5 | 70 | 15 | 68.8 |
| 8BNCU15/18.5 | 3,000 | 7.5 | 70 | 15 | 70.8 |
| 8BNCU18/16.5 | 3,500 | 7.5 | 65 | 15 | 68.8 |
| 8BNCU18/18.5 | 3,500 | 7.5 | 65 | 15 | 70.8 |
| 8BNCU20-21.5 | 4,000 | 7.5 | 60 | 15 | 73.5 |
| 8BNCU20/18.5 | 4,000 | 7.5 | 60 | 15 | 70.8 |
Specifications
- Electrical System: 36 V Electrical System
- Length to Forkface: 68.5 - 70.5 in
- Load Capacity: 3,000 - 4,000 lb. Load Capacity
- Overall Width: 41.5 in
- Overhead Guard Height: 88 in
- Travel Speed Full Load: 7.5 mph Travel Speed Full Load
Features
- Up to 23‘ Lift height
- Volt Motor: 36
- Built-In Analyzer
- Cushion Ride Suspension
- Temperature Indicator
- Independent Lift, Steer & Auxiliary Motors
- AC Induction Drive and Lift Motors
- Dual Electric Disk Brakes
- Emissions: 0
- Cushioned Padded Backrest & Armrest
- One-Piece Top Cover
- MPH Travel Speed: 7.5
- Cornering Speed Control
- Up to 4,000 lb. Lifting Capacity
- 36 Volt Electrical System
- Battery Compartment Rollers
- Navigation in 10‘ aisles
- Low Step Height
- Self-Diagnostics
- Programmable Maintenance Indicator
- High Visibility Mast & Overhead Guard
- Flexible Side Stance Operator Compartment
- Hydrostatic Power Steering
- AC Transistor Control System with MOSFET
- Spacious Operator Compartment
- Hydraulic Mast Cushioning
- Low-Effort Brake Pedal
- Maintenance Indicator
- Integrated Clipboard, Amenity Tray & Cup Holder
- Regenerative Braking
