Toyota Reach Truck (2,500-4,500 LBS)
| Make | Toyota |
| Model | Reach Truck (2,500-4,500 LBS) |
| Type | Reach Trucks |
How can we help?
Description
Overview
Toyota’s electric Reach Trucks deliver on efficiency, safety and performance like never before. With many new, unique features coupled with the longstanding productivity, ergonomics and low cost of ownership you expect from Toyota Forklift, the Toyota Reach Truck line opens up new opportunities in warehouses and distribution centers.
Quality-Packed Reach Truck
With world-class engineering and dependability, Toyota’s new reach fork truck is the perfect solution for your warehouse. Toyota’s Reach Truck comes in single and double reach models to help you utilize your warehouse space more efficiently. Choose between 24 volt or 36-volt power as well as battery compartments as short as 14.5 inches to as long as 21.5 inches. Longer maintenance intervals and over 500 engineering improvements make the Toyota Reach Truck the elite warehouse solution!
Models
Continued Performance
According to recent studies by Peerless Research Group, more and more forklift owners plan to keep their forklifts for 10+ years! Just like a car, truck or other motorized asset, periodic maintenance, service and upkeep is required, even under normal operating conditions, to keep your Toyota Industrial Stacker operating to peak performance. It is not uncommon for Toyota forklift owners to well exceed 10 years of use, as long as the forklift is properly maintained. Paired with a Planned Maintenance (PM) Plan, the Industrial Stacker can be an asset for your company for years to come.
Reach Truck
| Model Number | Load Capacity* (lbs.) | Max. Travel Speed Full Load (MPH) | Max. Lift Speed Full Load (FPM) | Max. Gradeability Full Load (%) | Basic Right Angle Stack** (IN.) |
|---|---|---|---|---|---|
| 9BDRU13 | 2,500 | 6.5 | 40 | 14 | N/A |
| 9BDRU15 | 3,000 | 7.5 | 75 | 14 | N/A |
| 9BRU18 | 3,500 | 6.5 (24V) 7.5 (36V) | 40 (24V) 70 (36V) | 14 | N/A |
| 9BRU23 | 4,500 | 7.5 | 65 | 14 | N/A |
Specifications
- Length to Fork Face: 55.3 - 67 in
- Load Capacity: 2,500 - 4,500 lb. Load Capacity
- Mast Lowered Height: 89 - 135 in
- Maximum fork height: Up to 30.5 feet Maximum fork height
- Overall Width: 43 - 61 in
- Travel Speed Full Load: 6.5 - 7.5 MPH Travel Speed Full Load
Features
- High-Visibility Overhead Guard
- UL-E Rating
- Self Diagnostics
- Key Switch
- AC-Powered Drive System with Torque Control
- Battery Compartment Rollers
- AC Hydraulic System
- Emissions: 0
- Up to 30.5‘ Lift Height
- Navigation in Narrow Aisles
- Wide-View 3-Stage Mast (FSV)
- 24/36 Volt Electrical System
- 180-Degree Electronic Power Steering
- Bubble-Cushioned Padded Floor & Brake Pedal
- Anti-Static Ground Strap
- battery box for more versatility: 18.5“
- Ergonomically-angled floorboard
- Integrated Clipboard, Amenities Tray & Cup Holder
- Emergency Power Disconnect Switch
- Up to 4,500 lbs. Lift Capacity
- Cushioned Knee Pad
- Battery Discharge Indicator w/ Lift Interrupt
- Self-Adjusting Electric Disc Brake
- Interactive Digital Display Panel
- Comfort-Padded Lean Points
- increase of maintenance intervals: 50%
- Electric Horn
- Safety Glass Mast Guard
- High-Visbility Overhead Guard
- Battery Retaining Gates (Adjustable)
- Built-In Analyzer
